SpatiX V3mini GNSS RTK Receiver
The SpatiX V3mini GNSS RTK Receiver is a compact IMU-enabled receiver designed for professional surveying and engineering applications. Its lightweight form factor makes it suitable for mobile field work where portability and efficient point collection are important.
The V3mini provides 1520-channel multi-constellation GNSS positioning and 0–60° IMU tilt measurement. It also supports SpatiX positioning services and network-independent field operations, helping surveyors maintain efficient workflows in areas where conventional network connectivity may be limited.
RTKSurvey supplies the SpatiX V3mini for surveying, construction, mapping and engineering applications.
Key Features
1520-channel multi-constellation GNSS
0–60° IMU tilt measurement
200 Hz IMU update rate
Network-independent positioning capability
4G and eSIM connectivity
Compact and lightweight design
IP68 protection
Designed for mobile field surveying
Core Specifications
GNSS channels: 1520
Satellite systems: GPS, GLONASS, Galileo, BeiDou, QZSS and SBAS
RTK accuracy: H ±(8 mm + 1 ppm), V ±(15 mm + 1 ppm)
Static accuracy: H ±(2.5 mm + 0.5 ppm), V ±(5 mm + 0.5 ppm)
Tilt range: 0–60°
IMU update rate: 200 Hz
Connectivity: 4G / eSIM / Wi-Fi
Protection: IP68
Weight: Approx. 800 g
Applications
Engineering surveying
Land surveying
Topographic mapping
Construction layout
Earthwork surveying
Utility and pipeline surveys
GIS field data collection
