STEC SDi Pro Laser Visual GNSS RTK Receiver

The STEC SDi Pro Laser Visual GNSS RTK Receiver combines GNSS RTK positioning with long-range laser measurement and camera-based visual surveying. It is designed for measuring points that are difficult, unsafe or inconvenient to occupy directly, such as points across roads, behind fences or at elevated structures.

The red laser system uses Automatic Gain Control to improve distance measurement under different light conditions, while dual cameras support visual AR stakeout. With an internal 2 W radio and rugged IP68 construction, the SDi Pro provides a flexible solution for demanding surveying and construction projects. RTKSurvey supplies the STEC SDi Pro for professional field applications.

Key Features

• GNSS RTK positioning
• Red laser measurement
• Laser measurement range up to 150–200 m
• 3 cm positioning accuracy within 20 m
• Automatic Gain Control for laser measurement
• Dual cameras for AR stakeout
• STEC fusionAR Gen 2
• 2 W internal radio
• Anti-interference antenna design
• IP68 protection
• Designed for remote and hard-to-reach point measurement

Core Specifications

GNSS Positioning: Multi-constellation GNSS RTK
Laser Type: Red laser
Laser Measurement Range: Up to 150–200 m
Laser Positioning Accuracy: 3 cm within 20 m
Laser Technology: Automatic Gain Control (AGC)
Imaging Sensor Resolution: 1920 × 1080
Optical Format: 1/2.8"
Cameras: Dual cameras
AR Stakeout: STEC fusionAR Gen 2
Internal Radio Output: 2 W
Radio: Anti-interference antenna design
Protection: IP68

Applications

• Topographic surveying
• Construction stakeout
• Engineering surveying
• Remote point measurement
• Road and bridge surveying
• Measurement across roads and obstacles
• Points behind fences or restricted areas
• Building and infrastructure surveying
• Laser-assisted AR stakeout
