Used Leica TS02 Total Station

The Leica TS02 is a practical manual total station designed for standard surveying, construction and stakeout tasks. It combines precise angle measurement, prism distance measurement, optional reflectorless EDM and Leica FlexField Plus onboard software. Actual condition, configuration and included accessories may vary by unit. Contact RTKSurvey.com for current availability.

Key Features

• 3″, 5″ and 7″ angular accuracy options

• Up to 3,500 m prism measurement range

• Optional reflectorless EDM

• 30× telescope

• Quadruple-axis compensation

• Leica FlexField Plus onboard software

• Graphical illuminated display

• Laser plummet

• Up to 24,000 stored fixpoints

• GSI, DXF, LandXML and ASCII data formats

• IP55 protection

Used Leica TS02 for Standard Surveying

The used Leica TS02 is suitable for routine topographic surveys, construction layout, stakeout, road work, as-built measurement and general field surveying. Its straightforward manual operation and practical measurement functions make it a cost-effective option for standard surveying tasks.

For used equipment, buyers should confirm the actual angular accuracy, EDM configuration, software, battery condition and included accessories before purchase.

Core Specifications

• Model: Leica TS02 / TS02plus

• Angular accuracy: 3″ / 5″ / 7″ depending on configuration

• Prism range: up to 3,500 m

• Reflectorless range: up to 500 m or higher depending on EDM option

• Prism distance accuracy: 1.5 mm + 2 ppm

• Reflectorless accuracy: 2 mm + 2 ppm

• Telescope magnification: 30×

• Compensator: quadruple-axis

• Display: illuminated graphic black-and-white display

• Internal memory: up to 24,000 fixpoints

• Software: Leica FlexField Plus

• Data formats: GSI, DXF, LandXML and ASCII

• Plummet: laser

• Protection: IP55

Applications

• Topographic surveying

• Construction surveying

• Building layout

• Stakeout

• Road surveying

• As-built measurement

• Engineering surveys

• General field measurement
