Used Leica TS06 Total Station

The Leica TS06 is a widely used manual total station for surveying, construction and engineering applications. Available in multiple angular accuracy versions, it combines precise angle measurement, reflectorless EDM options and Leica FlexField Plus field software. Actual condition, configuration and included accessories may vary by unit. Contact RTKSurvey.com for current availability.

Key Features

• Multiple angular accuracy options, including 1″, 2″, 3″, 5″ and 7″

• Up to 3,500 m prism measurement range

• R500 or R1000 reflectorless EDM options

• 30× telescope

• Quadruple-axis compensation

• Leica FlexField Plus onboard software

• Laser plummet

• USB and serial data interfaces

• Bluetooth available depending on configuration

• Up to 100,000 fixpoints

• IP55 protection

Used Leica TS06 for Surveying and Construction

The used Leica TS06 is suitable for topographic surveying, construction layout, stakeout, road projects, as-built measurement and general engineering work. Its manual operation, reflectorless measurement capability and onboard surveying applications make it a practical choice for routine field work.

Because used TS06 instruments may have different accuracy and EDM configurations, buyers should confirm the actual model specification, reflectorless range, software, battery condition and included accessories before purchase.

Core Specifications

• Model: Leica TS06 / TS06plus

• Angular accuracy: 1″ / 2″ / 3″ / 5″ / 7″ depending on configuration

• Prism range: up to 3,500 m

• Reflectorless range: over 500 m or over 1,000 m depending on EDM

• Prism distance accuracy: from 1.5 mm + 2 ppm

• Reflectorless accuracy: 2 mm + 2 ppm

• Telescope magnification: 30×

• Compensator: quadruple-axis

• Internal storage: up to 100,000 fixpoints

• Data formats: GSI, DXF, LandXML and ASCII

• Software: Leica FlexField Plus

• Display: illuminated monochrome display

• Plummet: laser

• Protection: IP55

Applications

• Topographic surveying

• Construction surveying

• Building layout

• Stakeout

• Road surveying

• As-built measurement

• Engineering surveys

• General field measurement
