Used Leica TS11 Total Station

The Leica TS11 is an advanced manual total station from the Leica Viva series, designed for surveying, construction and engineering applications. It combines Leica SmartWorx Viva software, reflectorless EDM, a color touchscreen and optional imaging and GNSS capabilities. Actual condition, configuration and included accessories may vary by unit. Contact RTKSurvey.com for current availability.

Key Features

• 1″, 2″, 3″ and 5″ accuracy options

• Leica SmartWorx Viva onboard software

• PinPoint R500 or R1000 reflectorless EDM

• Up to 3,500 m prism measurement range

• Electronic Guide Light (EGL)

• 5″ full-VGA color touchscreen

• Optional 5 MP wide-angle camera on TS11 I

• Optional Leica SmartStation GNSS capability

• Laser plummet

• Bluetooth, USB, RS232 and SD card interfaces

• 1 GB internal memory

• IP55 protection

Used Leica TS11 for Advanced Field Surveying

The used Leica TS11 is suitable for topographic surveying, construction layout, stakeout, engineering measurement and projects requiring a more advanced manual total station workflow. SmartWorx Viva provides graphical field applications, while optional imaging and GNSS functions can extend the instrument for more integrated surveying tasks.

For used equipment, buyers should confirm the actual angular accuracy, TS11 or TS11 I configuration, EDM range, imaging and GNSS options, software, battery condition and included accessories before purchase.

Core Specifications

• Model: Leica TS11 / TS11 I

• Angular accuracy: 1″ / 2″ / 3″ / 5″ depending on configuration

• Prism range: up to 3,500 m

• Reflectorless range: R500 >500 m / R1000 >1,000 m

• Prism distance accuracy: 1.0 mm + 1.5 ppm

• Reflectorless accuracy: 2 mm + 2 ppm

• Telescope magnification: 30×

• Compensator: quadruple-axis

• Display: 5″ Full-VGA color touchscreen

• Guide Light: Electronic Guide Light, 5–150 m

• Software: Leica SmartWorx Viva

• Memory: 1 GB internal

• Interfaces: RS232, USB, Bluetooth, SD card

• Battery: Lithium-Ion

• Operating time: approximately 14 hours

• Protection: IP55

Applications

• Topographic surveying

• Construction surveying

• Building layout

• Stakeout

• Engineering surveys

• As-built measurement

• GNSS-assisted surveying

• General field measurement
